mod_rt_sc_opacity Module Reference

Opacity and Planck source of the short-characteristics (SC) radiative transfer. More...

Data Types
interface	rt_sc_chib_iface
	The opacity and source the solvers call. rt_sc_setup points it at one of the built-in routines, or at usr_rt_sc_chiB for 'usr'. More...

Functions/Subroutines
subroutine, public	rt_sc_chib_rosseland (ixil, ixol, w, x, chi, bpl)
	Table Rosseland opacity, chi = kappa_R(rho, T) rho, and source B = a T^4, both multiplied by the transition switch.
subroutine, public	rt_sc_chib_kramers (ixil, ixol, w, x, chi, bpl)
	Analytic H-minus and Kramers opacity, with the source and the switch as in rt_sc_chiB_rosseland.
subroutine	chib_builtin (ixil, ixol, w, x, chi, bpl, tabulated)
	chi and B of the built-in opacities, the table when tabulated is set and the analytic fit otherwise. Temperature and gas pressure come from the EoS, so the opacity follows whichever EoS the run uses, and the switch scales chi and B together, so that the switched-off gas is both transparent and dark
pure double precision function, public	rt_sc_switch (t_k, p_code)
	Transition switch of the built-in opacities, from the temperature in K and the gas pressure in code units. The temperature gate is one in cool gas and falls to zero across dTcap above Tcap, while the pressure gate rises from zero to one across dp_TR dex around p_TR. A cell keeps its transfer when either holds, so the larger gate wins.
double precision function	kappa_code_cell (t_code, rho_code)
	Rosseland opacity of one cell from the table, with temperature, density and opacity all in code units.
double precision function	interp_logkappa (lt, lr)
	Bilinear interpolation of log10 kappa in (log10 T, log10 R).
integer function	op_locate (xx, n, xq)
	Index jl of the table interval [xx(jl), xx(jl+1)] that holds xq, found by bisection. A point beyond either end returns the first or the last interval.
subroutine, public	read_opacity_table ()
	Read the Rosseland table and shift it to code units. The file is in cgs, with T in K and R = rho/T6^3, where T6 is the temperature in 1e6 K.

Variables
character(len=10), public	rt_sc_opacity = 'Rosseland'
	The opacity model, either 'Rosseland' (the table), 'Kramers' (the analytic fit) or 'usr', which uses the usr_rt_sc_chiB callback.
character(len=std_len), public	rt_sc_kappa_table = 'rosseland_combined.tab'
	The Rosseland table file, read in rt_sc_setup when the table model is chosen.
double precision, public	rt_sc_tcap = 2.0d4
	The built-in opacities keep the SC transfer on where the gas is cool (T < Tcap) or dense (p > p_TR), and switch it off smoothly in the hot, tenuous corona. The transition bands Tcap and dTcap are in K, p_TR is in dyn/cm^2 and its width dp_TR in dex.
double precision, public	rt_sc_dtcap = 5.0d3
double precision, public	rt_sc_p_tr = 1.0d0
double precision, public	rt_sc_dp_tr = 0.5d0
double precision, public	rt_sc_lp_tr = 0.0d0
	log10 of p_TR in code units, set by rt_sc_setup
double precision, dimension(:), allocatable	op_logt
	The Rosseland table, shifted to code units when it is read. It holds log10 kappa on a grid of log10 T and log10 R, where R = rho/T^3, all three in code units.
double precision, dimension(:), allocatable	op_logr
double precision, dimension(:,:), allocatable	op_logk
integer	nt_op = 0
integer	nr_op = 0
procedure(rt_sc_chib_iface), pointer, public	rt_sc_chib => null()

Detailed Description

Opacity and Planck source of the short-characteristics (SC) radiative transfer.

The solvers never evaluate the gas themselves. They call the rt_sc_chiB callback, which returns chi = kappa rho and B = a T^4 on a block, with the temperature and gas pressure taken from the EoS, so that the opacity follows whichever EoS the run uses. rt_sc_setup points the callback at one of three models, chosen by rt_sc_opacity: Rosseland the tabulated Rosseland mean, shifted to code units when it is read, so that a cell needs one logarithm each of T and rho and one power of ten; Kramers an analytic H-minus and Kramers fit with electron scattering added; usr the user routine usr_rt_sc_chiB. The built-in models also apply the transition switch rt_sc_switch. It scales chi and B together, so that the hot, tenuous corona becomes both transparent and dark to the SC transfer, and the thin cooling takes over there. The module depends only on mod_global_parameters and mod_eos

Jack Jenkins (10.2026); More or less finished in v1 state for amrvac4.0

Function/Subroutine Documentation

chib_builtin()

subroutine mod_rt_sc_opacity::chib_builtin	(	integer, intent(in)	ixi,
		integer, intent(in)	l,
		integer, intent(in)	ixo,
			l,
		double precision, dimension(ixi^s,1:nw), intent(in)	w,
		double precision, dimension(ixi^s,1:ndim), intent(in)	x,
		double precision, dimension(ixi^s), intent(out)	chi,
		double precision, dimension(ixi^s), intent(out)	bpl,
		logical, intent(in)	tabulated )

chi and B of the built-in opacities, the table when tabulated is set and the analytic fit otherwise. Temperature and gas pressure come from the EoS, so the opacity follows whichever EoS the run uses, and the switch scales chi and B together, so that the switched-off gas is both transparent and dark

Definition at line 84 of file mod_rt_sc_opacity.t.

Here is the call graph for this function:

interp_logkappa()

double precision function mod_rt_sc_opacity::interp_logkappa	(	double precision, intent(in)	lt,
		double precision, intent(in)	lr )

Bilinear interpolation of log10 kappa in (log10 T, log10 R).

Definition at line 145 of file mod_rt_sc_opacity.t.

Here is the call graph for this function:

kappa_code_cell()

double precision function mod_rt_sc_opacity::kappa_code_cell	(	double precision, intent(in)	t_code,
		double precision, intent(in)	rho_code )

Rosseland opacity of one cell from the table, with temperature, density and opacity all in code units.

Definition at line 135 of file mod_rt_sc_opacity.t.

Here is the call graph for this function:

op_locate()

integer function mod_rt_sc_opacity::op_locate	(	double precision, dimension(n), intent(in)	xx,
		integer, intent(in)	n,
		double precision, intent(in)	xq )

Index jl of the table interval [xx(jl), xx(jl+1)] that holds xq, found by bisection. A point beyond either end returns the first or the last interval.

Definition at line 164 of file mod_rt_sc_opacity.t.

read_opacity_table()

subroutine, public mod_rt_sc_opacity::read_opacity_table

Read the Rosseland table and shift it to code units. The file is in cgs, with T in K and R = rho/T6^3, where T6 is the temperature in 1e6 K.

Definition at line 179 of file mod_rt_sc_opacity.t.

Here is the call graph for this function:

rt_sc_chib_kramers()

subroutine, public mod_rt_sc_opacity::rt_sc_chib_kramers	(	integer, intent(in)	ixi,
		integer, intent(in)	l,
		integer, intent(in)	ixo,
			l,
		double precision, dimension(ixi^s,1:nw), intent(in)	w,
		double precision, dimension(ixi^s,1:ndim), intent(in)	x,
		double precision, dimension(ixi^s), intent(out)	chi,
		double precision, dimension(ixi^s), intent(out)	bpl )

Analytic H-minus and Kramers opacity, with the source and the switch as in rt_sc_chiB_rosseland.

Definition at line 72 of file mod_rt_sc_opacity.t.

Here is the call graph for this function:

rt_sc_chib_rosseland()

subroutine, public mod_rt_sc_opacity::rt_sc_chib_rosseland	(	integer, intent(in)	ixi,
		integer, intent(in)	l,
		integer, intent(in)	ixo,
			l,
		double precision, dimension(ixi^s,1:nw), intent(in)	w,
		double precision, dimension(ixi^s,1:ndim), intent(in)	x,
		double precision, dimension(ixi^s), intent(out)	chi,
		double precision, dimension(ixi^s), intent(out)	bpl )

Table Rosseland opacity, chi = kappa_R(rho, T) rho, and source B = a T^4, both multiplied by the transition switch.

Definition at line 62 of file mod_rt_sc_opacity.t.

Here is the call graph for this function:

rt_sc_switch()

pure double precision function, public mod_rt_sc_opacity::rt_sc_switch	(	double precision, intent(in)	t_k,
		double precision, intent(in)	p_code )

Transition switch of the built-in opacities, from the temperature in K and the gas pressure in code units. The temperature gate is one in cool gas and falls to zero across dTcap above Tcap, while the pressure gate rises from zero to one across dp_TR dex around p_TR. A cell keeps its transfer when either holds, so the larger gate wins.

Definition at line 122 of file mod_rt_sc_opacity.t.

Variable Documentation

nr_op

integer mod_rt_sc_opacity::nr_op = 0

Definition at line 38 of file mod_rt_sc_opacity.t.

nt_op

integer mod_rt_sc_opacity::nt_op = 0

Definition at line 38 of file mod_rt_sc_opacity.t.

op_logk

double precision, dimension(:,:), allocatable mod_rt_sc_opacity::op_logk

Definition at line 37 of file mod_rt_sc_opacity.t.

op_logr

double precision, dimension(:), allocatable mod_rt_sc_opacity::op_logr

Definition at line 37 of file mod_rt_sc_opacity.t.

op_logt

double precision, dimension(:), allocatable mod_rt_sc_opacity::op_logt

The Rosseland table, shifted to code units when it is read. It holds log10 kappa on a grid of log10 T and log10 R, where R = rho/T^3, all three in code units.

Definition at line 37 of file mod_rt_sc_opacity.t.

rt_sc_chib

procedure(rt_sc_chib_iface), pointer, public mod_rt_sc_opacity::rt_sc_chib => null()

Definition at line 50 of file mod_rt_sc_opacity.t.

rt_sc_dp_tr

double precision, public mod_rt_sc_opacity::rt_sc_dp_tr = 0.5d0

Definition at line 32 of file mod_rt_sc_opacity.t.

rt_sc_dtcap

double precision, public mod_rt_sc_opacity::rt_sc_dtcap = 5.0d3

Definition at line 31 of file mod_rt_sc_opacity.t.

rt_sc_kappa_table

character(len=std_len), public mod_rt_sc_opacity::rt_sc_kappa_table = 'rosseland_combined.tab'

The Rosseland table file, read in rt_sc_setup when the table model is chosen.

Definition at line 27 of file mod_rt_sc_opacity.t.

rt_sc_lp_tr

double precision, public mod_rt_sc_opacity::rt_sc_lp_tr = 0.0d0

log10 of p_TR in code units, set by rt_sc_setup

Definition at line 34 of file mod_rt_sc_opacity.t.

rt_sc_opacity

character(len=10), public mod_rt_sc_opacity::rt_sc_opacity = 'Rosseland'

The opacity model, either 'Rosseland' (the table), 'Kramers' (the analytic fit) or 'usr', which uses the usr_rt_sc_chiB callback.

Definition at line 25 of file mod_rt_sc_opacity.t.

rt_sc_p_tr

double precision, public mod_rt_sc_opacity::rt_sc_p_tr = 1.0d0

Definition at line 32 of file mod_rt_sc_opacity.t.

rt_sc_tcap

double precision, public mod_rt_sc_opacity::rt_sc_tcap = 2.0d4

The built-in opacities keep the SC transfer on where the gas is cool (T < Tcap) or dense (p > p_TR), and switch it off smoothly in the hot, tenuous corona. The transition bands Tcap and dTcap are in K, p_TR is in dyn/cm^2 and its width dp_TR in dex.

Definition at line 31 of file mod_rt_sc_opacity.t.
